Nqe lus piav qhia:
Cov qauv tsim thiab kev ua haujlwm ntawm lub laj kab thiab hom tsheb ntawm lub laj kab cargo semi-trailer yog txhua yam tsim nyog raws li hom khoom thauj los ntawm tus neeg siv khoom. Nws tuaj yeem txaus siab tias qhov hnyav ntawm lub tsheb thauj khoom tuaj yeem txo qis thaum nqa lub nra. Cov qauv ntawm lub tsheb kuj yog qhov yooj yim thiab siv tau, uas yooj yim dua thaum dismantling, uas tuaj yeem txo tus nqi peev rau tus tswv tsheb.
Nta:
- Cov khoom siv ntau dua li lwm cov tuam ntxhab.
- Ntau lawm efficiency piv rau lwm manufacturers.
- Kev tswj kom zoo dua.
- Ib tug ntau trustworthy tom qab-muag system.
Specifications:
|
Zuag qhia tag nrho Dimension |
13000 * 2500 * 3020mm |
King pin |
Jost 90 Bolt-in King Pin |
|
laj kab loj |
700mm+150mm+650mm Tag nrho: 1500mm. Tshem tau |
Tare luj |
10000 kg |
|
Kuv beam thickness |
Heavy luag hauj lwm thiab ntxiv durability tsim I bea, Upper 14mm, qis 16mm, Middle 8mm |
Axles |
4 qag, FENGBAO 13T nrog pem hauv ntej qag liftable nrog Airbag |
|
Khoom siv hauv pem teb |
4mm thickness checker phaj |
laj kab qhov siab |
1500mm, tshem tau |
|
tsaws iav |
JOST E100 |
Nplooj caij nplooj ntoos hlav |
10-daim nplooj nplooj hlav |
|
Roj lub thawv |
1000L Galvanized roj tank |
Chaw thau khoom muaj peev xwm |
60tons, 70tons, 80tons |
|
Log Rim |
9.00-22.5, 16 daim nrog ib qho khoom seem |
Lub log |
12R22.5 tubeless log, 16 daim nrog ib qho khoom seem |
|
Braking System |
WABCO RE 6 relay valve; T30/30+T30 Caij nplooj ntoos hlav nres chamber; 40L cua tso tsheb hlau luam |
Kev pleev xim |
Ua kom tiav Chassis xuab zeb blasting los ntxuav xeb, 1 lub tsho tiv no ntawm anticorrosive prime, 2 lub tsho tiv no ntawm cov xim kawg |
Peb qhov zoo:
Peb qhov kev pabcuam:
Peb lav tias peb yuav teb koj cov lus nug / email ASAP.
Peb lav tias koj yuav tau txais cov khoom zoo dua los ntawm peb.
Peb lav tias Samples yuav xa tuaj rau koj thaum ntxov.
Peb lav tias koj yuav tau txais kev pabcuam thiab ua haujlwm zoo.
Peb lav tias cov khoom yuav raug xa tawm ASAP
Peb lav tias cov kev cai customized yuav raug txais.
Cov kev pabcuam kws tshaj lij pab txhawb tus nqi, cov kev pabcuam ntxaws txav cov neeg siv khoom, thiab txuas ntxiv tsim tus nqi rau cov neeg siv khoom.
Kev xav ntawm cov neeg siv khoom yog peb qhov khoom plig zoo tshaj plaws.
Vim li cas thiaj xaiv peb?
1. 20 xyoo kev paub.
2. Kev ua haujlwm zoo. Ib txwm cog lus rau kev tshawb fawb thiab kev txhim kho.
3. Xyuas kom cov khoom ua tau raws li tus qauv zoo.
4. Xyuas kom cov khoom xa tuaj raws sijhawm.
5. Peb yuav teb koj tam sim ntawd.
6. Muab kev pabcuam sov so thiab tus phooj ywg thiab kev pabcuam tomqab muag.
7. Tau lees paub qhov zoo thiab kev pabcuam zoo tshaj plaws, raws li koj yuav los ntawm cov neeg muag khoom hauv zos.
FAQ:
Packing & Shipping:
